What Are The Common Standard Shaft End Dimensions of Ball Screw?

Views: 25     Author: Site Editor     Publish Time: 2023-12-18      Origin: Site

What Are The Common Standard Shaft End Dimensions of Ball Screw?

The ball screw nominal diameter is the outer diameter of the ball screw,and the common specifications are 12mm,14mm,16mm,20mm,25mm,32mm,40mm,50mm.The ball screw diameter and the load are basically proportional,and the larger the diameter,the larger the load.Ball screw has the characteristics of high precision,high efficiency and high rigidity.



ALM designs and produces a wide range of ball screw


ALM has been specializing in the production of ball screws for 20 years,and our ball screw series products include custom ball screws,micro rolled ball screws,micro ground ball screws,standard ball screws,large ground ball screws,and bi-directional ball screws.We can produce ballnuts of various shapes and shaft end machining sizes according to customer requirements.



The following lists the common diameter of 18mm,20mm,25mm,28mm,30mm ball screw standard shaft end machining sizes.Customers can refer it when designing ball screw.For more model number ball screw standard shaft end machining, pls refer to ALM catalog.ALM End bearing support.pdf


●Diameter 18mm,20mm ball screw standard shaft end machining size

Diameter 18mm, 20mm ball screw standard shaft end dimension size


●Diameter 25mm,28mm,30mm ball screw standard shaft end dimensions


Diameter 25mm, 28mm, 30mm ball screw standard shaft end machining dimensions


If you need other diameter ball screw and end machining,email us to send you drawing right now!
