HK2001A
ALM
8479909090
HK2001A Clamping Element For HIWIN 20mm EG/HG Series Linear Guide
HK2001A clamping element is suitable for most linear guide brands on the market,for example,HIWIN 20mm EG/HG series.The clamping force of this rail clamp is 1200N,the tightening torque is 7.00[Nm],and installation direction is from above.
| Material | Steel |
Range of application | Suitable for most linear guides on the market |
| Quality standard | ISO9001:2015,CE certificate,RoHS and reach compliance |
| Guide rail series | 20mm |
Clamping force | 1200N |
| Packing | Carton+Plastic bag + Wooden box or according to customers' demands |
| Type | Manual |
| Working temperature | 0℃～50℃ |
HK2001A Clamping Element For HIWIN 20mm EG/HG Series Linear Guide
HK2001A clamping element is suitable for most linear guide brands on the market,for example,HIWIN 20mm EG/HG series.The clamping force of this rail clamp is 1200N,the tightening torque is 7.00[Nm],and installation direction is from above.
| Material | Steel |
Range of application | Suitable for most linear guides on the market |
| Quality standard | ISO9001:2015,CE certificate,RoHS and reach compliance |
| Guide rail series | 20mm |
Clamping force | 1200N |
| Packing | Carton+Plastic bag + Wooden box or according to customers' demands |
| Type | Manual |
| Working temperature | 0℃～50℃ |
