| Quantity: | |
|---|---|
MKS1501A
ALM
8479909090
MKS Series Pneumatic MKS1501A Clamping Element for 15mm Linear Rail
Pneumatic MKS1501A linear clamper,also known as guide rail lock,clamper,brake,etc.The main uses of the clamper are:fixing the slide,precise positioning,preventing vibration and improving rigidity.
MKS1501A Clamping Element Information
| Material | 20Crmo+Nickel Plating |
Range of application | Suitable for most linear guides on the market |
| Quality standard | ISO9001:2015,CE certificate,RoHS and reach compliance |
| Guide rail series | 15mm |
Clamping force | 400N |
| Packing | Carton+Plastic bag + Wooden box or according to customers' demands |
| Type | Pneumatic |
| Working temperature | 0℃～50℃ |
ALM's clamping element can replace zimmer's clamping element as follows
| ALM's model | Zimmer's model | Suitable for HIWIN rail |
| AKS15B | MKS1501A | HGH15/HGW15/EGH15/EGW15 |
| AKS20B | MKS2001A | HGH20/HGW20/EGH20/EGW20 |
| AKS25B | MKS2501A | HGH25/HGW25/EGH25/EGW25 |
| AKS30B | MKS3001A | HGH30/HGW30/EGH30/EGW30 |
| AKS35B | MKS3501A | HGH35/HGW35/EGH35/EGW35 |
| AKS45B | MKS4501A | HGH45/HGW45/EGH45/EGW45 |
| AKS55B | MKS5501A | HGH55/HGW55/EGH55/EGW55 |
| AKS65B | MKS6501A | HGH65/HGW65/EGH65/EGW65 |
Linear guide clamping dimension as follows
MKS Series Pneumatic MKS1501A Clamping Element for 15mm Linear Rail
Pneumatic MKS1501A linear clamper,also known as guide rail lock,clamper,brake,etc.The main uses of the clamper are:fixing the slide,precise positioning,preventing vibration and improving rigidity.
MKS1501A Clamping Element Information
| Material | 20Crmo+Nickel Plating |
Range of application | Suitable for most linear guides on the market |
| Quality standard | ISO9001:2015,CE certificate,RoHS and reach compliance |
| Guide rail series | 15mm |
Clamping force | 400N |
| Packing | Carton+Plastic bag + Wooden box or according to customers' demands |
| Type | Pneumatic |
| Working temperature | 0℃～50℃ |
ALM's clamping element can replace zimmer's clamping element as follows
| ALM's model | Zimmer's model | Suitable for HIWIN rail |
| AKS15B | MKS1501A | HGH15/HGW15/EGH15/EGW15 |
| AKS20B | MKS2001A | HGH20/HGW20/EGH20/EGW20 |
| AKS25B | MKS2501A | HGH25/HGW25/EGH25/EGW25 |
| AKS30B | MKS3001A | HGH30/HGW30/EGH30/EGW30 |
| AKS35B | MKS3501A | HGH35/HGW35/EGH35/EGW35 |
| AKS45B | MKS4501A | HGH45/HGW45/EGH45/EGW45 |
| AKS55B | MKS5501A | HGH55/HGW55/EGH55/EGW55 |
| AKS65B | MKS6501A | HGH65/HGW65/EGH65/EGW65 |
Linear guide clamping dimension as follows
