Diameter 10mm Lead 8mm Lead Screw Tr10X8

Long-lasting quality
Professional technical team
Complete after-sales service
Fast delivery:5~10 days
Availability:
Quantity:
  • Tr10x8

  • ALM

  • 8483900090

Diameter 10mm Lead 8mm Lead Screw Tr10X8 Lead Screw Tr10 is a miniature trapezoidal lead screw type.The diameter of the trapezoidal lead crew is10mm and the lead of the trapezoidal lead screw is 8mm.The trapezoidal lead screw pitch is 2mm.ALM has been engaged in linear motion component manufacturing for 16 years with outstanding screw product processing technology.ALM has a strong production capacity, sufficient supply,short delivery time and excellent after-sales service, which has won high praise from customers at home and abroad.

metric lead screw trapezoidal screw Tr8x10 (2)Linear lead screw

Model no:Tr10x8

Parameters:diameter:10mm, 2mm pitch, 4 starts, lead 8mm

Material:SUS304,C45

Nut material:POM,other lead nut materials are available upon request.

Customized nuts and end machining are available upon drawing

ALM Quality standard: ISO2901-2016 ,DIN103,GB/T5796-1-2005

Clearance: 7e


Other Available Material for Screw: ASTM1045, SUS303, SUS304, SS316, SS316L


Material for nut: Brass, Tin bronze, Phosphor bronze, Aluminum bronze, POM, PEK, nylon, Stainless steel, 1045, Zinc alloy, Brass+Plastic, Aluminum alloy+Plastic, Brass+Steel, Self lubricating(No oil type)


Available surface coating:Zinc-plated, nickel plated, hard chromium plated, fluorine coated,tungsten disulfide, black chorme plated etc.

Trapezoidal lead screw striking feature:

All ALM Trapezoidal screws have lead angles of 5° or less making them self-locking. Trapezoidal lead screws will not backdrive under most conditions. So you no need consider brakes or other holding devices to sustain loads for trapezoidal screws. All other screws except Acme series require some braking,that is to say,to prevent backdriving.


Trapezoidal lead screws and nuts are widely used and well suited for both manual and power drive applications including:

Pharmaceutical machinery

Packaging machinery

Slide drives

Metric valve stems

Medical device drives

Farm machinery

Screw press drives



Lead screw catalog-ALM.pdf


  To get more technical files,email to us now!

sales@autolinearmotion.com


Lead screw workshop

ALM possesses factory occupying 8000 square meters with 120 employees.Among which,more than 30 professional technical engineers in lead screws,ball screws and the mating linear motion parts.


All factory key manufacturing and testing equipments are imported from Japan, like CNC lathe, internal and external high-precision grinder, screw grinding machine, etc. ALM has passed the ISO9001:2015 and TS16949 Quality Management System.


The R&D achievements over many years bring the company more than 25 national patents on lead screw and ball screw design.



Production technology


Quality testing facilities


Quality testing
