| Quantity: | |
|---|---|
KK8605
ALM
8479909090
Width 86mm High Speed Heavy Duty Linear Actuator KK8605. ALM KK8605 linear module is driven by a ball screw while a guideway slides on anoptimized U-rail to achieve higher accuracy and greater stiffness.Using finite element analysis on the U-shaped cross section allows the volume and rigidity to be made balanced. Therefore, a high rigidity rail, compact design and a light weight design are also accomplished simultaneously.
| Material | Carbon steel |
| Black types | square, flange, lengthed |
| Accuracy grade | C grade or P grade |
Application | Automation Device;Transportation equipment;CNC machining centers;Heavy duty cutting machines;CNC grinding machines;Injection molding machines;Electric Discharge Machines;Plano millers;Devices requiring high rigidity and high load |
Other related products
DOWNLOAD A CATALOG:
Width 86mm High Speed Heavy Duty Linear Actuator KK8605. ALM KK8605 linear module is driven by a ball screw while a guideway slides on anoptimized U-rail to achieve higher accuracy and greater stiffness.Using finite element analysis on the U-shaped cross section allows the volume and rigidity to be made balanced. Therefore, a high rigidity rail, compact design and a light weight design are also accomplished simultaneously.
| Material | Carbon steel |
| Black types | square, flange, lengthed |
| Accuracy grade | C grade or P grade |
Application | Automation Device;Transportation equipment;CNC machining centers;Heavy duty cutting machines;CNC grinding machines;Injection molding machines;Electric Discharge Machines;Plano millers;Devices requiring high rigidity and high load |
