T6.35x12.7 Trapezoidal Lead Screw with Tr6.35 POM Square Nut
The trapezoidal lead screw diameter is 6.35mm and lead is 12.7mm.The lead screw with self-lubricating POM square nuts,which have the advantages of fast running speed and low friction,lead screw and nut can be flexibly designed according to your needs.
| Diamter | 6.35mm |
| Lead | 12.7mm |
| Length | According to your needs |
| Shaft end machining | Processing according to your requirements |
| Nut shape and dimension | According to your needs |
| Thread Direction | Right hand thread/left hand thread/right and left hand thread |
| Available screw material | ASTM1045,SUS303,SUS304,SS316,SS316L |
Available nut material | Brass,Tin bronze,Phosphor bronze,Aluminum bronze,POM,PEEK,nylon,POK,Stainless steel, 1045,Zinc alloy,Brass+Plastic,Aluminum alloy+Plastic,Brass+Steel,Self lubricating(No oil type) |
Available surface coating | Zinc-plated,nickel plated,hard chromium plated,fluorine coated,tungsten disulfide,black chorme plated,molybdenum disulfide. |
| Quality standard | ISO9001:2015,CE certificate,RoHS and reach compliance |
| Clearance | 7e,higher precision is available upon request |
| Lead accuracy | Can be 0.02mm/100mm |
Contact our sales staff to customize more lead screw details.
T6.35x12.7 Trapezoidal Lead Screw with Tr6.35 POM Square Nut
The trapezoidal lead screw diameter is 6.35mm and lead is 12.7mm.The lead screw with self-lubricating POM square nuts,which have the advantages of fast running speed and low friction,lead screw and nut can be flexibly designed according to your needs.
| Diamter | 6.35mm |
| Lead | 12.7mm |
| Length | According to your needs |
| Shaft end machining | Processing according to your requirements |
| Nut shape and dimension | According to your needs |
| Thread Direction | Right hand thread/left hand thread/right and left hand thread |
| Available screw material | ASTM1045,SUS303,SUS304,SS316,SS316L |
Available nut material | Brass,Tin bronze,Phosphor bronze,Aluminum bronze,POM,PEEK,nylon,POK,Stainless steel, 1045,Zinc alloy,Brass+Plastic,Aluminum alloy+Plastic,Brass+Steel,Self lubricating(No oil type) |
Available surface coating | Zinc-plated,nickel plated,hard chromium plated,fluorine coated,tungsten disulfide,black chorme plated,molybdenum disulfide. |
| Quality standard | ISO9001:2015,CE certificate,RoHS and reach compliance |
| Clearance | 7e,higher precision is available upon request |
| Lead accuracy | Can be 0.02mm/100mm |
Contact our sales staff to customize more lead screw details.
